2~8℃ Pharmaceutical Refrigerator

Type:HYC-360

Typical installations can be found in drug stores,epidemic prevention service centers,pharmaceutical companies,and many other places.



Refrigeration System

> Danfoss compressor an EBM fan for condenser.
> Forced air circulation for large airflow with optimized air channels to deliver superior temperature uniformity.
> Special evaporator design to increase cooling capacity for quick temperature pulldown and recovery.

Safety Control

> Alarms for system malfunctions,over and under temperature ,and sensor error.
> Alarm buzzer representation:audible and visible.
> Built-in chargble battery to sustain displaying the temperature and alarm for 73 hours if power failure.

Ergonomic Design

> Multilevel adjustable shelves for flexible storage of pharmaceutical products of various dimensions.
> Door lock ensures safety to prevent unauthorized access.
> Large LED digital display for easy observation.
> Wide voltage tolerance,suitable for application with unsteady voltage.
> Applicable ambient temperature range of 10 to 35℃ with humidity up to 60%.
> Polyurethane foam insulation,transparent double glass outer door.
> Lockable casters.
> Inner lights.

Transparency Design

> Digital display,cabinet temperature within 2~ 8℃.
> Power-on indicator.

Parameters

 Model No.  HYC-360
 Voltage(V/Hz)  220V/50
 Input power(w)  430
 Temp.range(℃)  2~ 8
 Exterior Dimension(mm)(WxDxH)  555X460XX1340
 Interior Demension(mm)(WxDxH)  620X655X1955
 Liters(L)  360
 Net/Gross(kg)  103/112
 Shelf/Inner doors  5/0
