  Pure Dry Air Generator

Laboratory Equipments













Click To Enlarge

Pure Dry Air Generator

Noblegen’s range of Pure Air Generators are some of the most efficient systems for laboratory use. Utilising the reliable and efficient PSA technique to dry wet air and make it suitable for instrument use. There are 2 models which run from a single phase supply, indicators are used to display outlet pressure and generating hours as a maintenance indicator. The Noblegen Pure Instrument Gas Generators are an important part of any efficient laboratory removing the need for high pressure gas cylinders.

Other flow-rates are available on request.



Standard Features

> Stand alone unit with internal compressor.
> Bench orwall mount
> Low maintenance
> 2 years warranty

Opti ons

> Additional in let & out let filtrat ion on request

Benefits

> Replaces high pressure gas cyl inders
> Constant gas qua l i ty
> Compact design
> Ideal for low and medium flow applications
> Very cost effective , fast payback

Techinical Specification

Model Inlet / Outlet
Flow l/min		 Dimensions mm (ins) Weight
Kg (lbs)
    Height
mm (ins)		 Width
mm (ins)		 Depth
mm (ins)
 AG3-1  3.0  650 (25)  320 (12.5)  650 (25.5)  40 (88)
 AG6-1  6.0  650 (25)  320 (12.5)  650 (25.5)  40 (88)

Techinical Data

 Ambient Temp range  5-35°C (41-95°F)
 Air Inlet Pressure  Internal Compressor
 Outlet Pressure  Up to 5 barg (72 psig)
 Electrical Supply  220v a.c. / 1ph / 50Hz or
 110v a.c. / 1ph / 50-60Hz
 Inlet / Outlet connections  G 1/4” (BSP) Female

  >> Quote Enquiry
