   Blood Collection Monitor


Blood Bank Equipments











Click To Enlarge

Blood Collection Monitor

Blood collection monitor is compact instrument to provides smooth &gentle rocking for homogeneous mixing with anticoagulant without clot formation of blood cell during collection of blood from donor

Calibration


The equipment is calibrated with the help of master calibrator ,which is certified for its accuracy for its accuracy by Electronic regional Testing Laboratory (ERTL) Government of India recognized testing laboratory with traceable reference to National Physical Laboratories.(NPL





  Special Features
  • Volume can be set in 1 ml. increments .
  • Provision of pausing collection & changed programmed volume during pause
  • Micro controller based program.
  • Volume can be set from 1ml to 999ml.
  • Display of weight & volume
  • Auto tare facility to accurate for the weight of the bag
  • Motor activated clamping at the end of the collection
  • Audio visual alarm to alert in case of any abnormal condition
  • Auto calibration
  • Overload indication
  • Highly user friendly system with LCD messages.
  • Display of the time taken for collection
  • Diagnostic mode for technical analysis.



  Technical Specification

Cat No. JA-09 JA-91

  Readably

  1ml/1g

  1ml/1g

  Display

  Large LCD

  Large LCD

  Alarm

  Audio-visual

  Audio-visual

  Input voltage

  230V AC (SMPS)

  90-270V AC (SMPS)

  Battery back up

  ---------------

  6 to 8 hrs.

  Calibration

  Automatic

  Automatic


  >> Quote Enquiry
