Digital display
• Model.
• Intel / Outlet Pressure
• Hours run meter
• PLC Status led. |
Application Industries
• GC
• Sample Preparation
• Solvent Evaporation |
Standard Features
> Generators ava i labl e wit h & without i nternal compressor
> Digit a l d isplay o f pressure ,mode l , hours run meter
> Al l pipe wor k i s copper t o increase gas qua l i ty
> Life- time warranty on PSA carbonsieve
Options
> Screen can be cus tomised for users design
> Ex Hazardous area version
Techinical Specification
| Model |
Model Inlet / Outlet
Flow l/min
(Air / N2) |
Dimensions mm (ins) |
Weight
Kg (lbs) |
| |
|
Height
mm (ins) |
Width
mm (ins) |
Depth
mm (ins) |
|
| ANG1-0 |
1.5 / 1.0 |
650 (25) |
320 (12.5) |
650 (25) |
20 (55) |
| ANG1-1 |
1.5 / 1.0 |
650 (25) |
320 (12.5) |
650 (25) |
45 (99) |
| ANG3-0 |
3.0 / 3.0 |
725 (28.5) |
450 (17.7) |
665 (26.1) |
58 (127) |
| ANG3-1 |
3.0 / 3.0 |
725 (28.5) |
450 (17.7) |
665 (26.1) |
80 (176) |
Techinical Data
| Ambient Temp range |
5-35°C (41-95°F) |
| Maximum air Inlet Pressure |
8 barg (116 psig) |
| N2 / Air Outlet Pressure |
5 barg |
| Gas Purity |
N2 99.9995% / Air -40°C |
| Air Inlet Requirement (units without compressor) |
Dewpoint: -40°C (-40°F)
Particulate: <0.1 micron
Oil: <0.01 mg/m³ |
| Electrical Suppl |
220v a.c. / 1ph / 50Hz or
110v a.c. / 1ph / 50-60Hz |
| Inlet / Outlet connections |
G 1/4” (BSP) Female |
|
