   Haematology Analyser or Cell counter


Blood Bank Equipments










Click To Enlarge

HEMA 2062 PLUS

Principles

Electrical resistance for counting & SFT method for hemoglobin

Parameters

WBC, Lymph, mid, gran, Lymph % ,  gran%, RBC, HGB, HCT, MCV, MCHC, RDW- CV, PLT, MPV, PDW,PCT, WBC histogram, RBC histogram, PLT histogram, P- LCR

Working mode

Double counting pathway + independent HGB detection system

Carryover

WBC<0.5%, RBC <0.5%, HGB< 0.5%, PLT<2%



Operating mode

Color window interface, figure button, mouse input

Interface

1 parallel interface, 2 USB interfaces, 2 RS232 interface(with net) ,1 VGA interface

Special featurers

  • 23 parameters, with 3 part WBC differential.
  • Aperture diameter 70.
  • 10 ul sampler volume.
  • Memory for 30,000 results including histograms.
  • Through put : 60sample/hour.
  • Automatic & manual calibration.
  • Automatic dilution when power ON/ OFF.
  • High voltage cleaning after each measurement .
  • QC mode : X –B ,L- J curve,SD,CV.

    • Performance

    Parameter

    Linearity range

     Precision

    WBC

    0.5~99.9x10/L

    CV<2.0%

    RBC

    0.2~9.99x10/L

    CV<1.5%

    HGB

    1.0~299.9 g/L

    CV<1.5%

    MCV

    40~200.0 fL

    CV<0.5%

    PLT

    0~ 999x10/L

    CV<4.0%

    Opening environment

    Temperature 15 C~30C
    Humidity 10%~ 85%

    Printout

    Thermal recorder, printer
    Optical external printer

    Display

    Large color LCD display, resolution: 640x480clot.

    Power requirement

    175-265V ~50/60Hz

    Weight

    25kg


      >> Quote Enquiry
